Keychron Q1 HE QMK Wireless Custom Keyboard (US Layout)

SKU: Q1H-P1
€213,00

Type
Color
Switches

The Fully Assembled version includes:
  •  The keyboard PCB, the case, and the aluminum plate.
  • Keycaps (included Mac & Windows keycaps).
  • Adjustable-actuation-point Gateron 2.0 magnetic switches.

No discount codes can be used for the Q1 HE.

Keychron Q1 HE

Meet the Q1 HE, the world's first 75% layout wireless QMK custom keyboard equipped with Hall Effect Gateron 2.0 magnetic switches. These switches provide a distinct advantage due to their unique mechanism, offering faster feedback, dynamic rapid triggering, and adjustable actuation points, resulting in epic enhancements for the gaming experience tailored to your individual preferences.

Keychron Q1 HE Wireless QMK/VIA Custom Mechanical Keyboard

In addition to the Hall Effect magnetic switches, the Q1 HE introduces a 2.4G connection mode with an impressive 1000Hz polling rate, further ensuring a lightning-fast gaming experience. But that's not all; it also boasts premium features such as Bluetooth connectivity, a double-gasket design, an all-aluminum body, PBT keycaps, and more.

Features of Keychron Q1 HE Wireless QMK/VIA Custom Mechanical Keyboard
Customize Your Q1 HE

Choose the keycaps, switches, and more accessories for your Q1 HE.

2.0 Magnetic Hall Sensor Switches

With the first invented dual-rail structure, extended tube structure design, and the special pre-lubed, these switches ensure unparalleled stability and smoothness like never before.

Installed with an optimal magnetic sensor with a sensitivity of only 0.1 mm, it offers more precious feedback. You can customize actuation points and assign multiple actions to a single key based on the travel depth you personalized, enhancing gameplay and providing a customized typing sensation.

Add Gateron Double-Rail Magnetic Switch to cart
Keychron Q1 HE Wireless QMK/VIA Custom Mechanical Keyboard

Adjustable Actuation Point

Customize each key with ultra-precise 0.1 mm sensitivity and adjustable actuation points ranging from 0.5 to 3.8 mm. Setting the actuation point to 0.8 mm or 1.0 mm shortens the trigger and increases sensitivity. The reset occurs once you release the key, ensuring a faster response.

Dynamic Rapid Trigger

Activate or deactivate keys based on travel distance rather than fixed points. They activate precisely upon pressing and deactivate upon letting go, allowing for immediate repetition of keystrokes in mod-motion. This enables you to execute a chain of actions in quick succession during gameplay.

Keychron Q1 HE Wireless QMK/VIA Custom Mechanical Keyboard

Multiple Actions, One Keystroke

Assign four actions to a single key based on the depth of your press. For example, lightly press a key to walk forward in a game, and press deeper to run. Additionally, releasing the key also supports two-stage settings. This allows for smoother, personalized combinations that can give you an edge in competitive gaming.

Keychron Q1 HE Wireless QMK/VIA Custom Mechanical Keyboard

Reassign Keys By The Keychron Launcher Web App

With the Keychron Launcher web app, you can effortlessly remap keys, adjust actuation points, set the magnetic switches, create personalized macro commands, shortcuts, and key combinations for each key.

Keychron Q1 HE Wireless QMK/VIA Custom Mechanical Keyboard

2.4 GHz & Bluetooth Connection

Experience peak gaming performance on the fly with the Q1 HE's 2.4 GHz wireless connection boasting a rapid 1000 Hz polling rate. For seamless multitasking across your computer, phone, and tablet, you can effortlessly connect the Q1 HE via Bluetooth 5.1 to three devices.

Keychron Q1 HE Wireless QMK/VIA Custom Mechanical Keyboard

Reassign Keys By The Web App

With the Keychron web app, you can effortlessly remap keys, adjust actuation points, set the magnetic switches, create personalized macro commands, shortcuts, and key combinations for each key.

Keychron Q1 HE Wireless QMK/VIA Custom Mechanical Keyboard

A Piece Of Metal Art

The entire metal body is crafted from 6063 aluminum, a material known for its increased durability, stability, and premium feel. Not only is this aluminum more resistant to physical damage, wear, and tear, but it is also environmentally friendly and recyclable. These qualities ensure both aesthetic appeal and a commitment to sustainability.

Keychron Q1 HE Wireless QMK/VIA Custom Mechanical Keyboard

Customize Every Part

To build a fully customizable keyboard, we designed every component to be able to assemble easily. Therefore, you can customize and adjust each component as you wish.

Structure of Keychron Q1 HE Wireless QMK/VIA Custom Mechanical Keyboard

Double-Gasket Design

Silicone pads between the top and bottom cases reduce acoustic resonance, maintaining gasket flexibility and enhancing typing sound. The keyboard's bottom has an acoustic pad, improving sound quality with a slight impact on flexibility. Users seeking more flexibility can opt to remove the acoustic pad.

Keychron Q1 HE Wireless QMK/VIA Custom Mechanical Keyboard
Keychron Q1 HE Wireless QMK/VIA Custom Mechanical Keyboard

An Epic Core Inside The Keyboard

Engineered with a powerful chip (MCU) with 256K flash and QMK open-source firmware to provide more flexibility for developers. The polling rate is 1000 Hz out of the box in Type-C wired mode and 2.4 GHz mode, which greatly helps when competitively gaming.

Suitable for All Devices

Built with the Mac users’ experience in mind while still retaining compatibility for Windows devices, the Q1 HE comes with a system toggle and an additional set of customized keycaps for both Windows and macOS systems. You can now save two different layouts on the keyboard, one for each system.

Keychron Q1 HE Wireless QMK/VIA Custom Mechanical Keyboard
Keychron Q1 HE Wireless QMK/VIA Custom Mechanical Keyboard

OSA Profile Double-shot PBT Keycaps

It has a similar height to that of the OEM profile and has an SA-like shape. We named it the OSA (OEM spherical angled) keycap. The PBT keycaps will provide excellent oil resistance, enhance the type feel, and prevent the legends from fading out.

Hot-swappable

The hot-swappable sockets are mounted on the PCB, so you can install or change the switches without soldering. The PCB supports both 3 pin and 5 pin MX mechanical switches.

Keychron Q1 HE Wireless QMK/VIA Custom Mechanical Keyboard

South-facing RGB LED Lights

The south-facing RGB is designed to better illuminate the keyboard backlight from the typist’s angle with the premium non-shine-through PBT keycaps installed. The south-facing RGB is also free from interference when the user installs Cherry-profile alternative keycaps on their keyboard.

All New Screw-In PCB Stabilizers

All New Screw-In PCB Stabilizers

The screw-in design increases stability and makes it easier for changes and upgrades. Precise craftsmanship makes the stabilizers more stable and less wobbly. The big keys’ (space bar, shift, enter, delete) typing experience is now more stable and smooth.

What's in the box?

Pack list of Keychron Q1 HE Custom Mechanical Keyboard
Pack list of Keychron Q1 HE Custom Mechanical Keyboard barebone version
differences-among-the-q-he-q-max-q-pro-series-keyboards

Specs

Width145 mm
Length327.5  mm
Front Height22.6 mm  (without keycaps)
Back Height35.8 mm (without keycaps)
Feet Height2.4 mm
Angle5.2°
Weight1735 g ± 10 g (Fully Assembled Version)
Body MaterialAluminum
PlateAluminum
Polling Rate1000 Hz (2.4 GHz and wired) / 90 Hz (Bluetooth mode)
Connectivity2.4 GHz/Bluetooth/ Type-C wired
Bluetooth Device NameKeychron Q1 HE
Battery4000 mAh Rechargeable li-polymer battery
Wireless Working Time (Backlit off) Up to 180 hours (Lab test result may vary by actual use)
Wireless Working Time (RGB) Up to 30 hours (Lowest brightness)
Charging Time Around 5 hours
Bluetooth Version 5.1
Compatible SystemWindows/macOS/Linux
N-Key Rollover (NKRO) Yes for both wireless and wired modes
Hot-swappable Yes. Compatible with most of the 3 pin & 5 pin MX mechanical switches such as Gateron, Cherry MX and Kailh, etc.
Keycaps (Fully Assembled Version)OSA Double-shot keycaps, not shine-through
MCUARM Cortex-M4 32-bit STM32F402RC (256KB Flash)
SwitchesGateron 2.0 magnetic switch
BacklightSouth-facing RGB LED
StabilizerScrew-in PCB stabilizer
Charging PortUSB Type-C
CableType-C cable + Type-A to Type-C adapter
Switch SupportHot-swappable (5 pin & 3 pin)
Operating Environment-10℃ to 50℃
Cable Length1.8 m
Charging PortUSB type-C
Keychron Q1 HE User Guide

Learn more about the Keychron Q1 HE such as the Q1 HE shortcuts, assembling the Q1 HE, factory reset, and more in the FAQ section.
